TEKNİK ÖZELLİKLER
ÖZELLİKLER | ZP 8 200 I | ZP 8 200 E | ZP 10 200 I | ZP 10 200 E | ZP 12 200 I | ZP 12 200 E | ZP 14 200 I | ZP 14 200 E |
Kullanım yeri | Internal | External | Internal | External | Internal | External | Internal | External |
Kapasite | 200 kg. | 200 kg. | 200 kg. | 200 kg. | 200 kg. | 200 kg. | 200 kg. | 200 kg. |
Kişi sayısı | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 |
Ağırlık | 402 kg. | 414 kg. | 517 kg. | 541 kg. | 554 kg. | 634 kg. | 618 kg. | 686 kg. |
A | 7,77 mt. | 7,77 mt. | 10 mt. | 10 mt. | 12 mt. | 12 mt. | 14 mt. | 14 mt. |
B | 5.77 mt. | 5.77 mt. | 8 mt. | 10 mt. | 10 mt. | 8 mt. | 12 mt. | 12 mt. |
C | 800 mm. | 800 mm. | 800 mm. | 800 mm. | 800 mm. | 800 mm. | 800 mm. | 800 mm. |
D | 1980 mm. | 1980 mm. | 1980 mm. | 1980 mm. | 2600 mm. | 2600 mm. | 2960 mm. | 2960 mm. |
E | 1380 mm. | 1380 mm. | 1380 mm. | 1380 mm. | 1380 mm. | 1380 mm. | 1380 mm. | 1380 mm. |
F | 670 mm. | 670 mm. | 670 mm. | 670 mm. | 670 mm. | 670 mm. | 670 mm. | 670 mm. |
G | 1060 mm. | 1060 mm. | 1060 mm. | 1060 mm. | 1060 mm. | 1060 mm. | 1060 mm. | 1060 mm. |
H | 2100 mm. | 1550 mm. | 2100 mm. | 3000 mm. | 2550 mm. | 5000 mm. | 3000 mm. | 5000 mm. |
I | 2100 mm. | 1550 mm. | 2100 mm. | 3000 mm. | 2550 mm. | 5000 mm. | 3000 mm. | 5000 mm. |
L | 540 mm. | 730 mm. | 580 mm. | 810 mm. | 810 mm. | 2050 mm. | 810 mm. | 2050 mm. |
M | 410 mm. | 600 mm. | 590 mm. | 820 mm. | 820 mm. | 2040 mm. | 820 mm. | 2040 mm. |
N | 400 mm. | 400 mm. | 400 mm. | 400 mm. | ||||
O | 1380 mm. | 1380 mm. | 1380 mm. | 1380 mm. | 400 mm. | 400 mm. | 400 mm. | 400 mm. |
P | 2550 mm. | 2550 mm. | 2550 mm. | 2550 mm. | 3000 mm. | 3000 mm. | 3250 mm. | 3250 mm. |
Q | 1800 mm. | 1800 mm. | 1800 mm. | 1800 mm. | 1700 mm. | 1700 mm. | 1700 mm. | 1700 mm. |
